This flow gauge is ideal for flow or leak test in the production line
Highly accurate and highly responsive sensor instantly measures the flow rate. DF-241BA is ideal for flow or leak test in the production line.
Air Leak Testers
Air Leak Tester is the automatic leak detector detects any leaks by the minute change of differential pressure and conducts OK/NG judgment. Ideal to be built into a production line for a laborsaving and a quality control purpose
Air Flow Testers
Variety ranges from F.S.10mL/min to F.S 500L/min are available. Promotes an automation and a laborsaving of the measurement
Helium / Hydrogen Leak Testers
Helium Leak Tester adopts the new testing method and Helium Leak Tester adopts the new testing method and
Pressure
All Manometer comes with a traceability. Wide range of Manometers, from a micro pressure (F.S. 200Pa) to a high pressure (F.S. 50MPa) are available
Peripherals
Peripheral instruments are used with Air Leak Tester in order to enhance its functionality and convenience
Sound / Vibration Analyser
We determine the acceptability of the sounds and vibrations of products using our special analyses developed in-house.
Cosmo Super Gel
Materials combining unprecedented flexibility and durability
Others
Highly accurate and highly responsive sensor instantly measures the flow rate. DF-241BA is ideal for flow or leak test in the production line.
| Number of Channels | 10 channels |
|---|---|
| Upper/Lower Limits | 4 Settings: HH, HI, LO, LL |
| Zero Adjustment | One push Zero method |
| Auto-Zero | Auto-Zero button |
| Display Hold | Hold button |
| Display Response | Digital Filter (High, Medium, Low) |
| RS-232C | 1200, 9600, and 19200 bps switchable |
| BCD Output | Open Collector |
| Display Digits | 3.5 digits (1999) and 4.5 digits (19999) |
| Sample Rate | 250 ms and 50 ms switchable |
| User Span | 0.001 to 9.999 (Default: 1.000) |
| (1) Flow Range | (2) Line Pressure | (3) Option | (4) Power Source | (5) Conversion Temperature | |||||
| Code | Unit | Code | Unit | Code | Description | Code | Description | Code | Description |
| □□ ML | □□ mL/min | □□ KP | □□ kPa | B | Low Line Pressure Sensor *1 | VG | AC Adaptor 100V Cable 3m | S | Conversion at 20℃ |
| □□ L | □□ L/min | □□ MP | □□ MPa | F1 | 5V Analog Output | VH | AC Adaptor 240V Cable 2m | N | Conversion at 0℃ |
| F2 | 10V Analog Output | VJ | Without AC Adaptor | ||||||
| F3 | Match with Display | ||||||||
*1 Low line pressure sensor (PT-103B-A) is used at 10 kPa or lower
| Model | Flow Range (Atm Pressure) | Maximum Line Pressure | Port Size | Temperature Sensor |
| LF-104 N – 10C | 0 to 10 mL/min | 990kPa | R1/4 | Built-in |
| LF-104 N – 20C | 0 to 20 mL/min | |||
| LF-104 N – 50C | 0 to 50 mL/min | |||
| LF-104 N -100C | 0 to 100mL/min | |||
| LF-104 N -200C | 0 to 200mL/min | |||
| LF-104 N -500C | 0 to 500mL/min | |||
| LF-104 N – 1L | 0 to 1 L/min | 700kPa | ||
| LF-104 N – 2L | 0 to 2 L/min | |||
| LF-104 N – 5L | 0 to 5 L/min | |||
| LF-104 N – 10L | 0 to 10 L/min | 500kPa | R1/2 | |
| LF-104 N – 20L | 0 to 20 L/min | |||
| LF-104 N – 30L | 0 to 30 L/min | |||
| LF-105B N – 50L | 0 to 50 L/min | 350kPa | ||
| LF-105B N -100L | 0 to 100 L/min | |||
| LF2-200L | 0 to 200 L/min | 50kPa | R3/4 | Connected to the outlet of Laminar Flow Tube |
| LF2-500L | 0 to 500 L/min |
